| Specifications |
|
Camera
|
|
Sensor
|
1/3", 4.0 MP, progressive scan, CMOS
|
|
Lens
|
2.8 mm @ f 2.0
|
|
DORI Distance
|
Lens (mm)
|
Detect (m)
|
Observe (m)
|
Recognize (m)
|
Identify (m)
|
|
2.8
|
63.0
|
25.2
|
12.6
|
6.3
|
|
4.0
|
90.0
|
36.0
|
18.0
|
9.0
|
|
Angle of view(H)
|
107.8°
|
|
Angle of View (V)
|
57.0°
|
|
Angle of View (O)
|
140.1°
|
|
Adjustment angle
|
Pan: 0° ~ 360°
|
Tilt: 0° ~ 80°
|
Rotate: 0° ~ 360°
|
|
Shutter Speed
|
Auto / Manual, 1 - 1/100,000 sec.
|
|
Minimum Illumination
|
Color: 0.01 Lux (f 2.0, AGC on)
0 Lux with IR on
|
|
Day / Night
|
IR-cut filter with auto switch (ICR)
|
|
Digital noise reduction
|
2D / 3D DNR
|
|
S/N
|
> 56 dB
|
|
IR Range
|
Up to 98 ft (30 m) IR range
|
|
Wavelength
|
850 nm
|
|
IR On / Off Control
|
Auto / Manual
|
|
Defog
|
Digital Defog
|
|
WDR
|
120 dB
|
|
Video
|
|
Video Compression
|
Ultra 265, H.265, H.264, MJPEG
|
|
H.264 code profile
|
Baseline profile, Main Profile
|
|
Frame Rates
|
Main Stream: 4 MP (2688 x 1520), up to 30 fps; 4 MP (2560 x 1440), up to 30 fps; 3 MP (2304 x 1296), up to 30 fps; 1080p (1920 x 1080), up to30 fps
Sub Stream: 720p (1280 x 720), up to 30 fps
Third Stream: 4CIF (704 x 576), up to 30 fps
|
|
Video Bit Rate
|
128 Kbps - 16 Mbps
|
|
OSD
|
Up to 4 OSDs
|
|
Privacy Mask
|
Up to 4 areas
|
|
ROI
|
Up to 4 areas
|
|
Motion Detection
|
Up to 4 areas
|
|
Imaging
|
|
White Balance
|
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2
|
|
Digital noise reduction
|
2D / 3D DNR
|
|
Smart IR
|
Support
|
|
Flip
|
Normal / Vertical / Horizontal / 180°
|
|
Dewarping
|
NA
|
|
HLC
|
Supported
|
|
BLC
|
Supported
|
|
Audio
|
|
Audio Compression
|
G.711
|
|
Suppression
|
Supported
|
|
Sampling Rate
|
8 KHz
|
|
Storage
|
|
Edge Storage
|
Micro SD, up to 256 GB
|
|
Network Storage
|
ANR
|
|
Network
|
|
Protocols
|
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL
|
|
Compatible Integration
|
ONVIF (Profile S, Profile G, Profile T), API
|
|
Client
|
LTS PRO-VS Station
|
|
Web Browser
|
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
|
|
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+
|
|
Interface
|
|
Network
|
1 x RJ45 10/100 Mbps Base-TX Ethernet
|
|
Built-in Mic
|
Supported
|
|
Certifications
|
|
Certifications
|
CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15
|
|
General
|
|
Power
|
12V DC ±25%, PoE (IEEE 802.3 af)
|
|
Power consumption: Max 5.5 W
|
|
Dimensions
(Ø x H)
|
Φ 4.6 x 3.8” (Φ 118 x 96 mm)
|
|
Net Weight
|
0.73 lb (0.33 kg)
|
|
Materials
|
Front Cover: Metal
Rear Cover, Bracket, Bottom Plate: Metal
|
|
Operating Conditions
|
-22° to 140° F (-30° to 60° C), Humidity: ≤95% RH (non-condensing)
|
|
Strorage Environment
|
-22° to 140° F (-30° to 60° C), Humidity: ≤95% RH (non-condensing)
|
|
Surge Protection
|
2 KV
|
|
Ingress Protection
|
IP67
|
|
